Specifications
Digital Output
| COAXIAL, OPTICAL & AES/EBU | PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
| DSD 2.8MHz (DoP) | |
| IIS LVDS | PCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz |
| DSD 2.82MHz, 3.07MHz, 5.64MHz, 6.14MHz, 11.29MHz, 12.29MHz, 22.58MHz, 24.58MHz | |
| USB DAC | Depends on the specifications supported by the connected USB DAC device. Not higher than PCM 32Bit/768kHz and DSD 24.58MHz. |
| The USB DAC port provides a maximum of 5V/1A low-noise power supply. |
Network
| LAN | 10/100/1000 Mbps |
| SFP | 10/100/1000 Mbps |
USB
| USB 3.0 * 2 | The USB port provides a maximum power of 5V/1A. |
| The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices. |
External Clock Input
| 10MHz / 50Ω / Sine wave or square wave input |
Trigger Interface
| Trigger Input | DC 6-12V<10mA |
| Trigger Output | DC 12V/50mA |
Storage Extension
|
M.2 2280 2260 2242 NVMe PCIe SSD slot *1 The maximum power specification provided by the expansion slot is DC 3.3V/3A. |
Power Specs
| Power Voltage |
AC 100V-120V 50/60Hz or AC |
| Standby Power Consumption | < 5W |
| Maximum Power Consumption | < 50W |
Weight & Size
| Weight | 4.6kg (10.14 pounds) |
| Size |
Width: 330 mm (12.99 inches), Depth: 267 mm (10.51 inches), Height: 97 mm (3.82 inches) |
Accessories
| Power cable * 1 | |
| Printed material * 1 |
