- Type
- MC
- Mass & Dimension
- 8.3g, 18 x 17.2 x 30.5mm (WxHxD)
- Stylus
- Solid Ultra Low-Mass 75µm x 2.5µm Microridge
- Cantilever
- ⌀0.28mm Boron Shaft
- Coils
- High-Purity Copper
- Internal Impedance
- 12Ω
- Load Impedance
- 100 – 1kΩ
- Frequency Response
- 10Hz – 50kHz
- Output
- 0.5mV @ 1kHz
- Channel Separation
- 30dB @ 1kHz
- Channel Balance
- 0.5dB @ 1kHz
- Compliance
- 8×10-6cm/dyn @ 100Hz
- Vertical Tracking Angle
- 20°
- Tracking Force Range
- 1.8g – 2.2g
- Recommended Tracking Force
- 2.0g
- Replacement Stylus Unit
- Re-Tip Exchange (See Dealer)
- Capacitance
- 100pF – 200pF
